Dump Semi Trailer

Loading Capacity:50Tons - 70Tons

Volume Capacity:35-40 CBM

Axle Number:3 Axles / 4 Axles

Kingpin Size:2.0 Inch / 3.5 Inch

  • Professional Service, Competitive Price.
  • Powerful Engine, Advanced Technologies.
  • Stable and Reliable Quality, Great Performance.

Model

Dump Semi Trailer

Dimension

11000 x 2500 x 3850mm(Outside); 10000 x 2350 x 1700mm(Inside)

Curb Weight

12500 KGS

Loading Capacity

70 Tons (40CBM)

Dump Body

NM450, bottom 6mm, side 3mm

Lifting System

Full set of HYVA hydraulic lifting cylinder

Kingpin

JOST 2.0 / 3.5 Inch

Landing Gear

JOST 28 Tons

Main Beam

Submerged arc welding, T700L high strength steel

Side Beam

18mm steel channel

Suspension

The first axle air suspension with lifting system, the rear three axles mechanical suspension with 10pcs leaf spring

Spring Leaf

90mm x 13mm x 10 layers

Axles

FUWA Brand, 13Tons * 4pcs

Tires

13R22.5 or 315/80R22.5

Brake Chamber

T30/30 + T30 spring brake chamber, one piece of 45L air tanks

Electrical

24V

Tool Box

1000 x 500 x 500 mm
